MITSUBISHI J2S drive repair
Model: MR-J2S-70A
Failure phenomenon: AL32 alarm
Failure analysis: the customer said that the servo is in the normal use of the AL32 alarm, turn off the power to restart and can be used, but more than ten minutes after the alarm. According to customer specification measurement module J2-Q02A normal, the measurement of the driving voltage is also normal. In the power to remove module shielding alarm is connected with the motor driving waveform measurement BW phase abnormal, replace the A3150V and 82UF/35V opto power capacitor after measuring found are consistent. Re install the module on the machine test everything is normal. Since then the use of customer feedback has not found this fault alarm.
Repair: the replacement of optocoupler A3150V and capacitor 82UF/35V in normal power supply.
Jiahong Serena repair MITSUBISHI server fault display, no phase, overcurrent, overvoltage, undervoltage, overload, overheat fault. AL-20, AL-24, AL-10, AL-32, AL-37, AL-51, E9, display, jitter.
